4524Q Brake Shoe

4524Q Brake Shoe

Part Number:4524Q

Product Size:16.5"*5"mm

Number of rivet holes:16

Product OE number:

contact iconContact Us
Part No. 4524Q

4524Q Brake Shoe

Stainless Steel · 16.5" × 5" · 16 Rivet Holes
4524Q Brake Shoe 4524Q · full display

Engineered from high-grade stainless steel, the 4524Q brake shoe delivers exceptional corrosion resistance and thermal stability for heavy-duty commercial vehicles. With a precise 16.5-inch by 5-inch footprint and 16 laser-calibrated rivet holes, it ensures perfect alignment with standard brake drums. The stainless steel substrate minimizes fade under repeated high-temperature braking, while the anti-squeal chamfer design reduces noise. This shoe is rigorously tested for endurance, making it a reliable choice for fleet maintenance and OEM replacements in demanding environments.

Core Advantages

  • Stainless steel construction · superior rust resistance
  • 16 precision rivet holes for balanced load distribution
  • Low-noise operation with optimized edge geometry
  • Compatible with Meritor, Dana & other major axles

Technical Specs

  • Dimensions: 16.5" × 5" (419 × 127 mm)
  • Rivet holes: 16 (dia. 8.2mm ±0.05)
  • Friction coefficient: 0.38 – 0.42 (hot)
  • Operating temp: -40°C to 450°C

Applications

Ideal for class 8 trucks, transit buses, and port tractors. The stainless steel formulation excels in coastal, humid, or winter-salting regions, preventing seizure and extending service life. Commonly used in 16.5" drum brake systems across North American and European commercial vehicle platforms.

Installation notes: Clean drum surface before fitting. Torque rivets to 25–30 N·m in a cross pattern. Allow 200–300 km of gentle braking for proper bedding. Inspect lining thickness every 10,000 km; replace if below 8mm.

Frequently Asked Questions

Q: Is the 4524Q compatible with all 16.5" drums?

Yes, it is designed to fit standard 16.5" brake drums. The 16-hole pattern matches most OEM configurations for heavy-duty trucks and buses.

Q: How does stainless steel compare to cast iron?

Stainless steel offers far better corrosion resistance and maintains consistent friction under wet or salty conditions. It also exhibits less thermal fade during prolonged downhill braking.

Q: What is the recommended replacement interval?

Inspection is recommended every 10,000 km. Replace the shoe when the friction lining wears down to 8mm or less, or if uneven wear or cracking is observed.

about Zhejiang Bangchi

ZHEJIANG BANGCHI AUTO PARTS CO.,LTD IS AN EXPERT IN AUTO PARTS MANUFACTURING INDUSTRY

Zhejiang Bangchi Auto Parts Co., Ltd. is a China 4524Q Brake Shoe Manufacturers and Custom 4524Q Brake Shoe OEM Exporter, Company, with more than 20 years of experience in the brake products industry. We can improve our product quality constantly by strict management and under the rules of the IATF 16949 quality system and the FMSI part number system. The goal of the FMSI standard is to provide performance data for aftermarket brake parts based on the approved Friction Materials Standards Institute specifications. It is important for your aftermarket products to also follow the same quality standards as your OEM products. For instance, all friction material components must be designed to comply with the same part numbering system. Our customers can rest assured that purchasing your products and installing them will be uniform and consistent. With an annual capacity of over 3 million pcs of brake shoes, we also offer steel brake shoes.
