Custom A6594200319 Brake shoe

Home / Products / Steel Brake Shoe / A6594200319 Brake shoe

ALL products

Home / Products / Steel Brake Shoe / A6594200319 Brake shoe
A6594200319 Brake shoe

A6594200319 Brake shoe

Part Number:BZ180

Product Size:410*180mm

Number of rivet holes: 16

Product OE number:  A 659 420 0319

contact iconContact Us
OE A 659 420 0319

A6594200319 Brake Shoe

Overview Specs Procurement Service

The A6594200319 Brake Shoe (BZ180) is a friction component engineered for commercial drum brake systems on heavy-duty axles. Its 410mm by 180mm braking surface and 16 rivet holes deliver even clamping force and consistent stopping performance across mixed-load duty cycles. The steel construction provides stable thermal behavior and predictable lining wear, while controlled tolerances support fast workshop fitting. Supplied for volume replacement programs, this shoe helps fleet operators reduce downtime and control maintenance spending without compromising braking reliability.

Size 410 × 180 mm
Rivet Holes 16 (Ø9.0mm)
Material Steel
Brake Type Drum

Technical Data

Product Size410 × 180 mm
Rivet Holes16 (Ø9.0mm)
Part NumberBZ180
OE NumberA 659 420 0319
MaterialSteel
Friction Coeff0.38 – 0.42
Max Operating Temp450 °C

Procurement Benefits

  • Volume supply with batch traceability
  • Direct interchange with OE A 659 420 0319
  • Consistent tolerances for fast fitting
  • Predictable wear for cost planning
  • Reduced vehicle downtime for fleets
  • Flexible delivery scheduling for maintenance programs

Fleet Applications

  • Heavy-duty commercial trailers
  • Long-haul and regional fleets
  • Municipal service vehicles
  • Mixed-load duty cycles
  • Volume maintenance programs

Workshop Notes

Fitting: Verify drum diameter and surface finish. Torque rivets to 30–35 N·m in a diagonal sequence. Bedding: 200–300 km of moderate braking. Inspection: every 12,000 km; replace below 8mm or at first sign of cracking or glazing.

Buyer Questions

Q: Is the BZ180 a direct replacement for OE A 659 420 0319?

Yes. The 410 × 180 mm footprint and 16-hole pattern are designed as a direct interchange for OE A 659 420 0319 on compatible drum brake systems.

Q: Can volume deliveries be aligned with our maintenance schedule?

Yes. Batch production and scheduled deliveries can be arranged to match fleet maintenance cycles and inventory planning.

Q: What is the recommended inspection interval?

Under normal mixed-load duty cycles, inspect every 12,000 km. Replace when lining thickness falls below 8mm or if uneven wear or glazing appears.

Q: Can the material be customized?

Customized material grades may be available for volume orders. Please confirm the target specification and order quantity with our team.

about Zhejiang Bangchi

ZHEJIANG BANGCHI AUTO PARTS CO.,LTD IS AN EXPERT IN AUTO PARTS MANUFACTURING INDUSTRY

Zhejiang Bangchi Auto Parts Co., Ltd. is a China A6594200319 Brake shoe Manufacturers and Custom A6594200319 Brake shoe OEM Exporter, Company, with more than 20 years of experience in the brake products industry. We can improve our product quality constantly by strict management and under the rules of the IATF 16949 quality system and the FMSI part number system. The goal of the FMSI standard is to provide performance data for aftermarket brake parts based on the approved Friction Materials Standards Institute specifications. It is important for your aftermarket products to also follow the same quality standards as your OEM products. For instance, all friction material components must be designed to comply with the same part numbering system. Our customers can rest assured that purchasing your products and installing them will be uniform and consistent. With an annual capacity of over 3 million pcs of brake shoes, we also offer steel brake shoes.
